Electrically controlled 4 wheel drive switch system without manual shit rod and switch can best give you the optional devices of 2WD and 4WD as you like. The air chargeable dual canister style shock absorber reduce vacant stroke or disconnection and also improves the comfort and operation stability at high speed. Moreover, liquid suspension effectively reduce the influence to the vehicle caused by engine vibration.

ZXAUTO Grand Tiger is equipped with Advance Diesel Technology engine featuring best performance and power.

ZXAUTO Grand Tiger also come with Anti-lock Braking System and Electronic Brake-force Distribution for added safety.
GRAND TIGER | DIESEL |
MAKE | Dongfeng Chaoyang Diesel |
MODEL | BQ2023RQ |
ENGINE | CYQD29Ti – EURO II |
TYPE | Diesel Inline 4 Cylinder |
Single Over Head Camshaft | |
MAX POWER (KW/RPM) | 80.9/3600 |
MAX TORQUE (Nm/rpm) | 221/2200 |
BORE/STROKE | 96 X 102 |
COMPRESSION RATIO | 22:01 |
DISPLACEMENT | 2951 |
CLUTCH | |
TYPE | DRY FRICTION, DIAPHRAGM SPRING |
TRANSMISSION | |
TYPE & MODEL | Three -axis Mechnic Transmission case |
NO. OF SPEED | 5 Forwarding Gears, 1 Reverse Gear |
Gear Ratio: | |
1st Gear | 4.31 |
2nd Gear | 2.33 |
3rd Gear | 1.44 |
4th Gear | 1.01 |
5th Gear | 0.81 |
Reverse Gear | 4.22 |
CHASSIS | |
Type | Ladder Type Channel Section |
Dimension | 120 X 60 X 3 |
Suspension Front | Independent suspension |
Type of Spring | Torsion bar spring |
Suspension Rear | Leaf spring |
Type of Spring | Symmetric semi-elliptic leaf spring |
Shock Absorber Front | Bi-directional telesopic shock absorber |
Shock Absorber Rear | Bi-directional telesopic shock absorber |
Min. Ground Clearence (mm) | 200 |
Min. Turning Radius (m) | 6.5 |
Max. Speed (Km/Hr) | 130 |
BRAKES | |
Type | Vaccum assisted Dual circuit hydraulic brakes |
Control System | ABS + EBD |
Service Brakes | |
Front Wheels | Disc Brakes |
Rear Wheels | Drum Brakes |
Parking Brakes | Cable Control acting or rear wheels |
STERING SYSTEM | |
Type | Energy absorbing type |
Rim | Alloy Rims |
Tyre Size | 235/70R16 or 245/70R16 |
DIAMENSIONS | |
Weight Kerb (Kg) | 1860 (4WD) |
Pay Load (Kg) | 675 |
Gross vehicle weight (Kg) | 2535 |
Fuel Tank Capacity | 73 L |
